وزن |
1000 g |
شرکت سازنده |
دی لینک-D-Link
|
نوع سوئیچ |
هوشمند
|
تعداد پورت |
20پورت
|
نوع پورت ها |
16 پورت گیگ, 4 پورت SFP گیگ
|
پورت POE |
ندارد
|
پورت SFP |
دارد
|
تعداد پورت SFP |
4
|
وضعیت قرار گیری در رک |
رکمونت
|
سایز قرارگیری در رک |
19-inch standard rackmounting width or with rackmountable brackets
1U Height
|
پورت ها |
16 10/100/1000 Mbps, 4 SFPs
|
استاندارد پورت |
“IEEE 802.3 10BASE-T Ethernet, IEEE 802.3u 100BASE-TX Fast Ethernet, IEEE 802.3ab 1000BASE-T
Gigabit Ethernet, IEEE 802.3x Flow Control for Full-Duplex Mode, Auto-negotiation”
|
توانایی سوئیچینگ |
40 Gbps
|
شیوه تبادل داده |
Store-and-forward
|
ظرفیت جدول |
16,000 entries per device
|
نحوه به روز رسانی |
Mac Address “Up to 256 static MAC entries
Enable/disable auto-learning of MAC addresses”
|
Media Interface Exchange |
Auto or configurable MDI/MDIX
|
نرخ ارسال پکت های حداکثر 64 بایتی |
29.8 Mpps
|
ظرفیت حافظه بافر پکتها |
1 MB per device
|
میزان صدای دستگاه |
0 dB(A)
|
گرمای تولید شده |
47.97 BTU/hr
|
برق ورودی |
100 to 240 VAC 50/60 Hz internal universal power supply
|
ماکزیمم میزان مصرف برق |
14.06 W
|
صرفه جویی در مصرف برق |
7.2 W
|
فن |
0
|
Storage Temperature |
-20 to 70˚C (-4 to 158 ˚F)
|
OperataTEMPERATURE |
-5 to 50 ˚C (23 to 122 ˚F)
|
Operation Humidity |
0% to 95% non-condensing
|
Storage Humidity |
0% to 95% non-condensing
|
ابعاد |
“440 x 140 x 44 mm
(17.32 x 5.51 x 1.73 inches)
19” standard rack mounting
width, 1U height”
|
وزن |
3000 گرم
|
چراغهای وضعیتی |
“Power (per device), Link/Activity/Speed (per 10/100/1000
Mbps port), Link/Activity/Speed (per SFP port)”
|
گواهینامه ها |
“FCC Class A, CE Class A, ICES-003
VCCI Class A, C-Tick, BSMI”
|
قابلیت های لایه 2 |
“MAC Address Table: 16K
• Flow Control
• 802.3x Flow Control
• HOL Blocking Prevention
• Jumbo Frame up to 10,000 Bytes
• IGMP Snooping
• IGMP v1/v2 Snooping
• Supports 256 IGMP groups
• Supports at least 64 static multicast addresses
• IGMP per VLAN
• Supports IGMP Snooping Querier
• MLD Snooping
• Supports MLD v1/v2 awareness
• Supports 256 groups
• Fast Leave
• Spanning Tree Protocol
• 802.1D STP
• 802.1w RSTP
• Loopback Detection
• 802.3ad Link Aggregation
• DGS-1210-10P: Max. 5 groups per device/8 ports per group
• DGS-1210-20: Max. 10 groups per device/8 ports per group
• DGS-1210-28/28P: Max. 14 groups per device/8 ports per
group
• DGS-1210-52: Max. 26 groups per device/8 ports per group
• Port Mirroring
• One-to-One, Many-to-One
• Supports Mirroring for Tx/Rx/Both
• Multicast Filtering
• Forwards all unregistered groups
• Filters all unregistered groups
• LLDP, LLDP-MED”
|
VLAN |
“802.1Q Tagged VLAN
• VLAN Group
• Max. 256 static VLAN groups
• Max. 4094 VIDs
• Management VLAN
• Asymmetric VLAN
• Auto Voice VLAN
• Max. 10 user-defined OUI
• Max. 8 default OUI
• Auto Surveillance VLAN”
|
Quality of Service (QoS) |
“802.1p Quality of Service
• 4 queues per port
• Queue Handling
• Strict
• Weighted Round Robin (WRR)
• Bandwidth Control
• Port-based (Ingress/Egress, min. granularity for
10/100/1000Base-T ports is 64 Kb/s)
• CoS based on
• 802.1p Priority Queues
• DSCP
• ToS
• TCP/UDP port number
• IPv6 traffic class”
|
Access Control List (ACL) |
“ACL based on
• MAC Address
• IPv4 Address (ICMP/IGMP/TCP/UDP)
• IPv6 Address (ICMP/TCP/UDP)
• 802.1p
• DSCP
• Ether type
• IPv6 traffic class
• DGS-1210-10P/20/28/28P
• Max. 50 profiles
• Max. 200 rules shared by profiles
• Single or multiple ports (each rule)
• DGS-1210-52
• Max. 50 profiles
• Max. 450 rules shared by profiles
• ACL Actions
• Permit
• Deny”
|
امنیت |
“Port Security
• Supports up to 64 MAC addresses per port
• Broadcast/Multicast/Unicast Storm Control
• Static MAC
• D-Link Safeguard Engine
• DHCP Server Screening
• Trusted Host
• ARP Spoofing Prevention
• Max. 64 entries
• SSL
• Supports v1/v2/v3
• Supports IPv4/IPv6
• Traffic Segmentation
• Smart Binding
• Discover connected devices and click to bind
• ARP Packet Inspection: 512 entries
• IP Packet Inspection: 128 entries
• Supports DHCP Snooping”
|
OAM |
Cable Diagnostics • Factory Reset
|
MIB |
“1213 MIB II
• 1493 Bridge MIB
• 1907 SNMP v2 MIB
• 1215 Trap Convention MIB
• 2233 Interface Group MIB
• D-Link Private MIB
• Power-Ethernet MIB
• LLDP MIB
• D-Link ZoneDefense MIB”
|
استاندارد های RFC |
RFC 783 TFTP
RFC 854 Telnet Server
RFC 951 BootP/DHCP Client
RFC 1157 SNMP v1, v2, v3
RFC 1213 MIB II, IF MIB
RFC 1215 MIB Traps Convention
RFC 1350 TFTP
RFC 1493 Bridge MIB
RFC 1542 BootP/DHCP Client
RFC 1769 SNTP
RFC 1901 SNMP v1, v2, v3
RFC 1907 SNMP v2 MIB
RFC 1908 SNMP v1, v2, v3
RFC 2068 FCS
RFC 2131 BootP/DHCP Client
RFC 2138 RADIUS Authentication
RFC 2139 RADIUS Authentication
RFC 2233 Interface Group MIB
RFC 2246 SSL
RFC 2475
RFC 2570 SNMP v1, v2, v3
RFC 2575 SNMP v1, v2, v3
RFC 2598 CoS
RFC 2616 FCS
RFC 2618 RADIUS Authentication
RFC 2819 RMON v1
RFC 2865 RADIUS Authentication
RFC 3164 System Log
RFC 3195 System Log
RFC 3411-17 SNMP
RFC 3621 Power Ethernet MIB
|
مدیریت وتنظیم دستگاه |
“Multi-Language Web-based GUI
• English (default)
• Simplified Chinese
• Traditional Chinese
• French
• German
• Italian
• Japanese
• Portuguese
• Russian
• Spanish
• SmartConsole Utility
• Simplified CLI
• Telnet Server
• TFTP Client
• IPv6 Neighbor Discovery
• Configurable MDI/MDIX
• SNMP
• Supports v1, v2, v3
• SNMP Trap
• System Log
• Max. 500 log entries
• BootP/DHCP Client
• SNTP
• ICMPv6
• IPv4/v6 Dual Stack
• DHCP Auto Configuration
• RMON v1″
|
گارانتی |
گارانتی 3 ساله ایزی
|
